Special Microcontroller Features:

• Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels
• Flash Program Memory with self read/write capability
• Internal 32MHz oscillator
• Integrated Capacitive mTouch Sensing Module
• Data Signal Modulator Module
• MI2C, SPI, EUSART w/auto baud
• Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels
• Flash Program Memory with self read/write capability
• Internal 32MHz oscillator
• Integrated Capacitive mTouch Sensing Module
• Data Signal Modulator Module
• MI2C, SPI, EUSART w/auto baud
• ECCP (Enhanced/Capture Compare PWM) Module
• Comparator with selectable Voltage Reference
• 4 Channel 10b ADC with Voltage Reference
• 25mA Source/Sink current I/O
• Two 8-bit Timers (TMR0/TMR2)
• One 16-bit Timer (TMR1)
• Extended Watchdog Timer (EWDT)
• Enhanced Power-On/Off-Reset
• Brown-Out Reset (BOR)
• In Circuit Serial Programming (ICSP)
• On Board In-Circuit Debug
• Wide Operating Voltage (1.8V – 5.5V)
• Low Power PIC12LF182x variants (1.8V – 3.6V)
• Standby Current (PIC12LF182X): 20 nA @ 1.8V, typical
• Active Current(PIC12LF1822): 50 uA/MHz @ 1.8V, typical

Applications

Automotive, Industrial, Consumer Electronics

Series Item

• PIC12F1822 • PIC12LF1822 • PIC16F1823 • PIC16LF1823 • PIC16F1824 • PIC16LF1824 • PIC16F1825 • PIC16LF1825 • PIC16F1826 • PIC16LF1826 • PIC16F1827 • PIC16LF1827 • PIC16F1828 • PIC16LF1828 • PIC16F1829 • PIC16LF1829
